Spec
Download
| Physical Property |
| System |
Linux |
| RAM |
128MB |
| ROM |
128MB |
| Front Panel |
Plastic |
| Power Supply |
BUS IN or DC 12V |
| Wi-Fi |
IEEE 802.b/g/n, 2.4 GHz |
| Installation |
Surface Mounting |
| Dimension |
195 x 130 x 14.5mm |
| Working Temperature |
-10℃ - +55℃ |
| Storage Temperature |
-10℃ - +60℃ |
| Working Humidity |
10%-90%RH (non-condensing) |
| Display |
| Display |
7-inch TFT LCD |
| Screen |
Capacitive touch screen |
| Resolution |
1024 x 600 |
| Audio & Video |
| Audio Codec |
G.711 |
| Video Codec |
H.264 |
| Networking |
| Protocol |
SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP
|
| Port |
| 2-Wire port |
2 |
| TF Card Slot |
1 |
-
Datasheet 904M-S3.pdfDownload
