Spec
Download
| Physical Property |
| System |
Linux |
| RAM |
64MB |
| ROM |
128MB |
| Front Panel |
Plastic |
| Power Supply |
PoE (802.3af) or DC12V/2A |
| Standby Power |
1.5W |
| Rated Power |
3W |
| Camera |
2MP, CMOS |
| Door Entry |
IC card(13.56MHz), APP |
| IP Rating |
IP65 |
| Installation |
Semi-flush mounting |
| Dimension |
170.5 x 111 x 38.6 mm |
| Working Temperature |
-40℃ - +55℃ |
| Storage Temperature |
-40℃ - +70℃ |
| Working Humidity |
10%-90% (non-condensing) |
| Audio & Video |
| Audio Codec |
G.711 |
| Video Codec |
H.264 |
| Video Resolution |
1280 x 720 |
| Viewing Angle |
100°(D) |
| Light Compensation |
LED white light |
| Networking |
| Protocol |
SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP |
| Port |
| Ethernet Port |
1 x RJ45, 10/100 Mbps adaptive |
| RS485 Port |
1 |
| Relay Out |
1 |
| Exit Button |
1 |
| Door Magnetic |
1 |
-
Datasheet 904M-S3.pdfDownload
