| Technical Details |
| Communication |
ZigBee |
| Shell Material |
PC +ABS (Fireproof) |
| Protection Class |
IP20 |
| Power Supply |
95~240 VAC, 50~60Hz |
| Power Consumption |
<1.5W |
| Fan Relay Amps Resistance |
5A; Inductive:3A |
| Valve Relay Amps Resistance |
3A; Inductive:1A |
| Sensor |
NTC3950, 10K |
| Set Temp. Range |
+5℃ - +35℃
|
| Accuracy |
±0.5℃ |
| Working Temperature |
0℃ - +45℃ |
| Ambient Humidity |
5% - 95% RH (Non-Condensing) |
| Storage Temperature |
-5℃ - +45℃ |
| Installation Box |
86x86 mm Square or European 60mm Round Box
|
| Dimensions |
88 x 88 x 42 mm |
-
Datasheet 904M-S3.pdfDownload
