| Physical Property of Door Station S212 (KIT) | |
| System | Linux |
| RAM | 64MB |
| ROM | 128MB |
| Front Panel | Aluminum |
| Power Supply | PoE (802.3af) or DC 12V/2A |
| Camera | 2MP, CMOS |
| Video Resolution | 1280 x 720 |
| Viewing Angle | 110°(H) / 60°(V) / 125°(D) |
| Door Entry | IC (13.56MHz) & ID (125kHz) Card, QR Code, Temp Key |
| IP/IK Rating | IP65 / IK07 |
| Installation | Surface Mounting |
| Dimension | 168 x 88 x 34 mm |
| Working Temperature | -40℃ - +55℃ |
| Storage Temperature | -40℃ - +70℃ |
| Working Humidity | 10%-90% (non-condensing) |
| Port of S212 (KIT） | |
| Ethernet | 1 x RJ45, 10/100 Mbps adaptive |
| RS485 | 1 |
| Relay Out | 2 |
| Reset Button | 1 |
| Input | 2 |
| Physical Property of Indoor Monitor E217W (KIT) |
|
| System | Linux |
| Display | 7-inch TFT LCD |
| Screen | Capacitive touch screen |
| Resolution | 1024 x 600 |
| RAM | 128MB |
| ROM | 128MB |
| Front Panel | Plastic |
| Power Supply | PoE (802.3af) or DC 12V/2A |
| Wi-Fi | IEEE802.11 b/g/n,@2.4GHz |
| Installation | Surface Mounting/Desktop |
| Dimension (Easy to Install Back Cover) | 195 x 130 x 14.5 mm |
| Working Temperature | -10℃ - +55℃ |
| Storage Temperature | -40℃ - +70℃ |
| Working Humidity | 10%-90% (non-condensing) |
| Port of E217W (KIT） | |
| Ethernet | 1 x RJ45, 10/100 Mbps adaptive |
| RS485 | 1 |
| Doorbell Input | 8 (Use any alarm input port) |
| Alarm Input | 8 |
| TF Card Slot | 1 |
| Audio & Video | |
| Audio Codec | G.711 |
| Video Codec | H.264 |
| Light Compensation | LED white light |
| Networking | |
| Protocol | Onvif, SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP |
| PoE Switch | |
| Port (1-4) | 10/100 Mbps PoE Ports |
| Port (5-6) | 10/100 Mbps Uplink Ports |
| POE Standard | IEEE802. 3af/at |
| Power Input | AC 100-240V 50/60Hz |
| Power Output | DC 52V1.25A |
| Operating Temperature | 0℃ - +40℃ |
| Storage Temperature | -40℃ - +70℃ |
| Storage Humidity | 10%-90% (non-condensing) |
| Dimension | 200 x 118 x 44 mm |
-
